Parameter | Singlemode Patchcord/Pigtail | Multimode Patchcord/Pigtail | ||
Polishing Type | PC | UPC | APC | PC |
Insertion loss(dB) | <=0.3dB,MTRJ<=0.5dB | <=0.3dB | <=0.3dB | <=0.3dB,MTRJ<=0.5dB |
Return loss(dB) | >=45dB,MTRJ>=35dB | >=55dB | >=65dB | |
Operating temperature | -20ºC~75ºC | |||
Storage Temperature | -40ºC~75ºC | |||
100 mating cycles loss | I.L changed≤0.1dB | |||
Durability | >1000 cycles |
Parameter | PC Polishing | APC Polishing | |
SC Type | LC Type | ||
R.O.C | 10~25mm | 7~25mm | 5~12mm |
Apex Offset | <50um | <50um | <50um |
Fiber Height | -125nm-50nm | -100nm-100nm | |
Polishing Angle | 8°± 0.3° |
